In [1]:
import marimo as mo
import pandas as pd
import numpy as np
import matplotlib.pyplot as plt
import seaborn as sns
import plotly.graph_objects as go
import plotly.express as px
from sklearn.model_selection import train_test_split
from IPython.display import Markdown, display

Bank Marketing Dataset Ethical Analysis¶

Project by Sharan Thakur GH1031360¶

No description has been provided for this image

Introduction¶

  • This notebook is assessment for M515 - Ethical Issues of AI.
  • This notebook uses the Bank Marketing Dataset from the UCI Machine Learning Repository.
  • The dataset contains information about direct marketing campaigns of a Portuguese banking institution.
  • The goal is to predict whether a client will subscribe to a term deposit based on various features and understand the issues with respect to bias and fairness in AI models.

GitHub Repository & Dataset:¶

  • GitHub Code Link: https://github.com/c2p-cmd/EthicalIssuesOfAI
  • Dataset Link: https://archive.ics.uci.edu/dataset/222/bank+marketing

Problem Statement¶

  • To analyze the Bank Marketing Dataset for potential ethical issues, including bias and fairness in AI models.
  • To identify any disparities in model performance across different demographic groups.

About the data:¶

Summary:¶

The data is related with direct marketing campaigns of a Portuguese banking institution. The marketing campaigns were based on phone calls. Often, more than one contact to the same client was required, in order to access if the product (bank term deposit) would be ('yes') or not ('no') subscribed.

There are four datasets:

  1. bank-additional-full.csv with all examples (41188) and 20 inputs, ordered by date (from May 2008 to November 2010), very close to the data analyzed in [Moro et al., 2014]
  2. bank-additional.csv with 10% of the examples (4119), randomly selected from 1), and 20 inputs.
  3. bank-full.csv with all examples and 17 inputs, ordered by date (older version of this dataset with less inputs).
  4. bank.csv with 10% of the examples and 17 inputs, randomly selected from 3 (older version of this dataset with less inputs). The smallest datasets are provided to test more computationally demanding machine learning algorithms (e.g., SVM).

The classification goal is to predict if the client will subscribe (yes/no) a term deposit (variable y).

Variable Info:¶

Input variables:

  1. age (numeric)
  2. job : type of job (categorical: "admin.","unknown","unemployed","management","housemaid","entrepreneur","student", "blue-collar","self-employed","retired","technician","services")
  3. marital : marital status (categorical: "married","divorced","single"; note: "divorced" means divorced or widowed)
  4. education (categorical: "unknown","secondary","primary","tertiary")
  5. default: has credit in default? (binary: "yes","no")
  6. balance: average yearly balance, in euros (numeric)
  7. housing: has housing loan? (binary: "yes","no")
  8. loan: has personal loan? (binary: "yes","no")
  9. contact: contact communication type (categorical: "unknown","telephone","cellular")
  10. day: last contact day of the month (numeric)
  11. month: last contact month of year (categorical: "jan", "feb", "mar", ..., "nov", "dec")
  12. duration: last contact duration, in seconds (numeric)
  13. campaign: number of contacts performed during this campaign and for this client (numeric, includes last contact)
  14. pdays: number of days that passed by after the client was last contacted from a previous campaign (numeric, -1 means client was not previously contacted)
  15. previous: number of contacts performed before this campaign and for this client (numeric)
  16. poutcome: outcome of the previous marketing campaign (categorical: "unknown","other","failure","success")

Output variable (desired target): 17. y - has the client subscribed a term deposit? (binary: "yes","no")

Data Loading & Preprocessing¶

In [2]:
df = pd.read_csv(
    "https://raw.githubusercontent.com/c2p-cmd/EthicalIssuesOfAI/refs/heads/main/bank_marketing_data.csv"
)
df.head()
Out[2]:
age job marital education default balance housing loan contact day_of_week month duration campaign pdays previous poutcome y
0 58 management married tertiary no 2143 yes no NaN 5 may 261 1 -1 0 NaN no
1 44 technician single secondary no 29 yes no NaN 5 may 151 1 -1 0 NaN no
2 33 entrepreneur married secondary no 2 yes yes NaN 5 may 76 1 -1 0 NaN no
3 47 blue-collar married NaN no 1506 yes no NaN 5 may 92 1 -1 0 NaN no
4 33 NaN single NaN no 1 no no NaN 5 may 198 1 -1 0 NaN no
In [3]:
Markdown(f"""### **Observation** The dataset has {len(df)} samples with {len(df.columns)} columns.""")
Out[3]:

Observation The dataset has 45211 samples with 17 columns.¶

In [4]:
df.info(show_counts=True)

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 45211 entries, 0 to 45210
Data columns (total 17 columns):
 #   Column       Non-Null Count  Dtype
---  ------       --------------  -----
 0   age          45211 non-null  int64
 1   job          44923 non-null  object
 2   marital      45211 non-null  object
 3   education    43354 non-null  object
 4   default      45211 non-null  object
 5   balance      45211 non-null  int64
 6   housing      45211 non-null  object
 7   loan         45211 non-null  object
 8   contact      32191 non-null  object
 9   day_of_week  45211 non-null  int64
 10  month        45211 non-null  object
 11  duration     45211 non-null  int64
 12  campaign     45211 non-null  int64
 13  pdays        45211 non-null  int64
 14  previous     45211 non-null  int64
 15  poutcome     8252 non-null   object
 16  y            45211 non-null  object
dtypes: int64(7), object(10)
memory usage: 5.9+ MB
In [5]:
pd.DataFrame(df.isnull().sum(), columns=["Count"])
Out[5]:
Count
age 0
job 288
marital 0
education 1857
default 0
balance 0
housing 0
loan 0
contact 13020
day_of_week 0
month 0
duration 0
campaign 0
pdays 0
previous 0
poutcome 36959
y 0

Observation There are missing values in job, education, contact, poutcome columns¶

In [6]:
df[df.isnull().sum()[df.isnull().sum() != 0].index.tolist()].head(10)
Out[6]:
job education contact poutcome
0 management tertiary NaN NaN
1 technician secondary NaN NaN
2 entrepreneur secondary NaN NaN
3 blue-collar NaN NaN NaN
4 NaN NaN NaN NaN
5 management tertiary NaN NaN
6 management tertiary NaN NaN
7 entrepreneur tertiary NaN NaN
8 retired primary NaN NaN
9 technician secondary NaN NaN

Imputation Strategy¶

  • For job column we will mark missing values as 'unknown'.
  • For education column we will mark missing values as 'unknown'.
  • We will drop contact column as it has too many missing values.
  • For poutcome column we will mark missing values as 'not-contacted'.
In [7]:
def clean_data(df: pd.DataFrame) -> pd.DataFrame:
    df["job"] = df["job"].fillna("unknown")
    df["education"] = df["education"].fillna("unknown")
    df = df.drop(columns=["contact"])
    df["poutcome"] = df["poutcome"].fillna("not-contacted")
    return df


cleaned_df = df.pipe(clean_data)
cleaned_df
Out[7]:
age job marital education default balance housing loan day_of_week month duration campaign pdays previous poutcome y
0 58 management married tertiary no 2143 yes no 5 may 261 1 -1 0 not-contacted no
1 44 technician single secondary no 29 yes no 5 may 151 1 -1 0 not-contacted no
2 33 entrepreneur married secondary no 2 yes yes 5 may 76 1 -1 0 not-contacted no
3 47 blue-collar married unknown no 1506 yes no 5 may 92 1 -1 0 not-contacted no
4 33 unknown single unknown no 1 no no 5 may 198 1 -1 0 not-contacted no
... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ...
45206 51 technician married tertiary no 825 no no 17 nov 977 3 -1 0 not-contacted yes
45207 71 retired divorced primary no 1729 no no 17 nov 456 2 -1 0 not-contacted yes
45208 72 retired married secondary no 5715 no no 17 nov 1127 5 184 3 success yes
45209 57 blue-collar married secondary no 668 no no 17 nov 508 4 -1 0 not-contacted no
45210 37 entrepreneur married secondary no 2971 no no 17 nov 361 2 188 11 other no

45211 rows × 16 columns

In [8]:
pd.DataFrame(cleaned_df.isnull().sum(), columns=["Count"])
Out[8]:
Count
age 0
job 0
marital 0
education 0
default 0
balance 0
housing 0
loan 0
day_of_week 0
month 0
duration 0
campaign 0
pdays 0
previous 0
poutcome 0
y 0
In [9]:
len(cleaned_df), len(cleaned_df.columns)
Out[9]:
(45211, 16)

Observation After cleaning, the dataset has 45211 samples with 16 columns and no missing values.¶

Exploratory Data Analysis (EDA)¶

In [10]:
features = cleaned_df.drop(columns="y").columns.tolist()
pd.DataFrame(features, columns=["Features of dataset"])
Out[10]:
Features of dataset
0 age
1 job
2 marital
3 education
4 default
5 balance
6 housing
7 loan
8 day_of_week
9 month
10 duration
11 campaign
12 pdays
13 previous
14 poutcome

Statistical Summary of Numerical & Categorical Features¶

In [11]:
cleaned_df[features].describe(include=[np.number])
Out[11]:
age balance day_of_week duration campaign pdays previous
count 45211.000000 45211.000000 45211.000000 45211.000000 45211.000000 45211.000000 45211.000000
mean 40.936210 1362.272058 15.806419 258.163080 2.763841 40.197828 0.580323
std 10.618762 3044.765829 8.322476 257.527812 3.098021 100.128746 2.303441
min 18.000000 -8019.000000 1.000000 0.000000 1.000000 -1.000000 0.000000
25% 33.000000 72.000000 8.000000 103.000000 1.000000 -1.000000 0.000000
50% 39.000000 448.000000 16.000000 180.000000 2.000000 -1.000000 0.000000
75% 48.000000 1428.000000 21.000000 319.000000 3.000000 -1.000000 0.000000
max 95.000000 102127.000000 31.000000 4918.000000 63.000000 871.000000 275.000000
In [12]:
cleaned_df[features].describe(include=["object"])
Out[12]:
job marital education default housing loan month poutcome
count 45211 45211 45211 45211 45211 45211 45211 45211
unique 12 3 4 2 2 2 12 4
top blue-collar married secondary no yes no may not-contacted
freq 9732 27214 23202 44396 25130 37967 13766 36959
In [13]:
plt.figure(figsize=(24, 26))
for f in features:
    if cleaned_df[f].dtype == "object":
        plt.subplot(4, 4, features.index(f) + 1)
        plt.pie(
            cleaned_df[f].value_counts(),
            autopct="%1.1f%%",
            labels=cleaned_df[f].value_counts().index,
            colors=sns.color_palette("pastel"),
        )
        plt.title(f"Distribution of {f}")
        plt.xticks(rotation=45)
        plt.grid()
    else:
        plt.subplot(4, 4, features.index(f) + 1)
        sns.histplot(cleaned_df[f], bins=30, kde=True, color="skyblue")
        plt.title(f"Distribution of {f}")
        plt.grid()
plt.show()
No description has been provided for this image

EDA Observations:¶

  • age: The distribution is right-skewed, with the majority of clients aged between 30 and 60.
  • job: "Blue-collar" (21.5%), "management" (20.9%), and "technician" (16.8%) are the three most common job types. "Student" (2.1%) and "unemployed" (2.9%) are among the least represented.
  • marital: Most clients are "married" (60.1%), followed by "single" (28.3%) and "divorced" (11.5%).
  • education: "Secondary" (51.3%) and "tertiary" (29.4%) education levels make up the vast majority of the dataset.
  • default: An overwhelming majority of clients (98.2%) have no credit in default.
  • balance: The distribution is extremely right-skewed, indicating that most clients have a low balance, while a few outliers have very high balances.
  • housing: A slight majority of clients (55.6%) do not have a housing loan.
  • loan: The vast majority of clients (84.0%) do not have a personal loan.
  • day_of_week: The distribution of calls appears relatively uniform across the days of the week, with slightly higher counts mid-week.
  • month: Marketing activity is not uniform. It peaks heavily in "May" (28.4%), followed by "July" (15.3%), "Aug" (13.8%), and "Jun" (11.8%).
  • duration: The call duration is heavily right-skewed, showing that most calls are short, with a long tail of longer-duration calls.
  • campaign: This feature is also very right-skewed. Most clients are contacted only a few times (1-3), while a small number of clients are contacted many times.
  • pdays: The histogram is dominated by a single value (likely -1, indicating not previously contacted), with very few clients having been contacted recently.
  • previous: This distribution is extremely skewed, with the vast majority of clients having 0 previous contacts.
  • poutcome: The outcome of previous campaigns is "unknown" for 81.7% of clients, which corresponds to the previous and pdays plots.

Summary:¶

age, marital, job and education are the "sensitive attributes."¶

Analysis of sensitive targets with target variable¶

In [14]:
plt.figure(figsize=(18, 12))
sensitive_attributes = ["age", "marital", "job", "education"]
for _attr in sensitive_attributes:
    plt.subplot(2, 2, sensitive_attributes.index(_attr) + 1)
    if cleaned_df[_attr].dtype == "object":
        sns.countplot(data=cleaned_df, x=_attr, hue="y", palette="Set2")
        plt.xticks(rotation=45)
    else:
        sns.histplot(
            data=cleaned_df,
            x=_attr,
            hue="y",
            multiple="stack",
            bins=30,
            palette="Set2",
        )
    plt.title(f"{_attr} vs Target Variable")
    if _attr == "age":
        plt.ylabel("Count")
    else:
        plt.ylabel("")
    plt.grid()
plt.show()
No description has been provided for this image

Insights from the plots on sensitive attributes.¶

age vs Target Variable¶

  • Absolute Counts: Most clients—both those who subscribed ("yes") and those who did not ("no")—fall within the 30–50 age range.
  • Subscription Rate (Proportion): The relative share of "yes" responses is highest among younger clients (around 20–30) and older clients (over 60). The middle-aged group (30–50) shows a lower overall subscription rate.

marital vs Target Variable¶

  • Absolute Counts: Married clients make up the largest share of both positive ("yes") and negative ("no") outcomes.
  • Subscription Rate (Proportion): Single clients show a higher likelihood of subscription compared to married or divorced clients.

job vs Target Variable¶

  • Absolute Counts: The majority of clients belong to the "blue-collar," "management," or "technician" categories.
  • Subscription Rate (Proportion): Subscription likelihood differs widely across occupations:
    • Higher Rates: "Student" and "retired" groups have the highest proportion of "yes" responses.
    • Lower Rates: "Blue-collar" and "entrepreneur" groups show the lowest proportion of subscriptions.
    • This indicates a notable disparity tied to socio-economic status.

education vs Target Variable¶

  • Absolute Counts: Most clients have "secondary" or "tertiary" education.
  • Subscription Rate (Proportion): The "tertiary" group shows a higher rate of subscriptions than the "secondary" and "primary" groups, while the "unknown" category also performs relatively well.

Analysis of non-sensitive targets with target variable¶

In [15]:
plt.figure(figsize=(21, 18))
non_sensitive_attributes = cleaned_df.drop(
    columns=["y"] + sensitive_attributes
).columns.tolist()
for _attr in non_sensitive_attributes:
    plt.subplot(4, 3, non_sensitive_attributes.index(_attr) + 1)
    if cleaned_df[_attr].dtype == "object":
        sns.countplot(data=cleaned_df, x=_attr, hue="y", palette="Set2")
    else:
        sns.histplot(
            data=cleaned_df,
            x=_attr,
            hue="y",
            multiple="stack",
            bins=30,
            palette="Set2",
        )
    plt.title(f"{_attr} vs Target Variable")
    if _attr == "default":
        plt.ylabel("Count")
    else:
        plt.ylabel("")
    plt.xlabel("")
    plt.grid()
plt.show()
No description has been provided for this image

Insights for the non-sensitive features.¶

default vs Target Variable¶

  • Observation: Nearly all clients do not have credit in default. The small subset of clients with a default shows a slightly lower subscription rate.

balance vs Target Variable¶

  • Observation: Most clients are concentrated at lower balance levels, where most outcomes also occur. However, the proportion of subscriptions tends to rise with higher balances, suggesting that clients with greater financial resources are more likely to subscribe.

housing vs Target Variable¶

  • Observation: Clients without a housing loan show a noticeably higher subscription rate compared to those who have one.

loan vs Target Variable¶

  • Observation: Similar to housing, clients without a personal loan are far more likely to subscribe than those with an existing loan.

day_of_week vs Target Variable¶

  • Observation: Subscription rates appear fairly stable across all days of the week, indicating that this feature may have limited predictive power.

month vs Target Variable¶

  • Observation: The subscription rate varies strongly by month.
    • Higher Rates: March, September, October, and December show a high proportion of subscriptions despite relatively low call volumes.
    • Lower Rates: May has the highest call volume but one of the lowest subscription rates.

duration vs Target Variable¶

  • Observation: Call duration is the most influential feature. Longer calls correspond to a much higher proportion of "yes" responses, while very short calls are mostly "no."
  • Critical Note: This maybe represents data leakage. Since duration is only known after the call ends, it cannot be used for prediction.

campaign vs Target Variable¶

  • Observation: The highest subscription rate occurs on the first contact, then declines sharply as the number of contacts within the same campaign increases.

pdays vs Target Variable¶

  • Observation: Most clients were not contacted previously (represented by the large "999" category). Among those who were, more recent contacts (lower pdays values) tend to correlate with higher subscription rates.

previous vs Target Variable¶

  • Observation: The majority of clients have no previous contact history. For those who do (even one or two prior interactions), the subscription rate is noticeably higher.

poutcome vs Target Variable¶

  • Observation: This feature is a strong predictor.
    • Clients with a previous campaign outcome of "success" show a very high subscription rate.
    • Those with outcomes of "failure" or "other" have lower rates.
    • Clients with an "unknown" outcome (the majority) show the lowest subscription rate overall.

Data Preparation¶

In [16]:
X = cleaned_df.drop(columns=["duration", "day_of_week", "default", "y"])
y = cleaned_df["y"]

X_train, X_test, y_train, y_test = train_test_split(
    X,
    y,
    test_size=0.2,
    random_state=19,
    stratify=y,
)
In [17]:
Markdown(
    f"""
### Data Sizes

* X train shape: `{X_train.shape}`
* X test shape: `{X_test.shape}`
* y train shape: `{y_train.shape}`
* y test shape: `{X_test.shape}`
"""
)
Out[17]:

Data Sizes¶

  • X train shape: (36168, 12)
  • X test shape: (9043, 12)
  • y train shape: (36168,)
  • y test shape: (9043, 12)
In [18]:
from IPython.display import JSON

numerical_features = X_train.select_dtypes(
    include=[np.number]
).columns.tolist()
categorical_features = X_train.select_dtypes(
    exclude=[np.number]
).columns.tolist()

JSON({
    "Numerical features": numerical_features,
    "Categorical features": categorical_features,
})
Out[18]:
<IPython.core.display.JSON object>
In [19]:
plt.figure(figsize=(10, 6))

plt.subplot(1, 2, 1)
plt.pie(
    y_train.value_counts(),
    autopct="%1.1f%%",
    labels=y_train.value_counts().index,
    colors=sns.color_palette("pastel"),
)
plt.title("Training Distribution of Target")
plt.grid()

plt.subplot(1, 2, 2)
plt.pie(
    y_test.value_counts(),
    autopct="%1.1f%%",
    labels=y_train.value_counts().index,
    colors=sns.color_palette("pastel"),
)
plt.title("Test Distribution of Target")
plt.grid()

plt.show()
No description has been provided for this image

Observation: Both Training and testing label has 88% no and 12% yes labels¶

Due to data imbalance in target we need to compute class weights for model to perform well¶

In [20]:
from sklearn.utils import compute_class_weight

class_names = np.unique(y)
weights = dict(
    zip(
        class_names,
        compute_class_weight(
            class_weight="balanced",
            y=y_train,
            classes=class_names,
        ),
    )
)
JSON(weights)
Out[20]:
<IPython.core.display.JSON object>
In [21]:
from sklearn.linear_model import LogisticRegression
from sklearn.ensemble import RandomForestClassifier
from sklearn.svm import SVC
from sklearn.pipeline import Pipeline
from sklearn.preprocessing import MinMaxScaler, OrdinalEncoder
from sklearn.compose import ColumnTransformer

ct = ColumnTransformer(
    [
        ("cat", OrdinalEncoder(), categorical_features),
        ("num", MinMaxScaler(), numerical_features),
    ]
)

svm = Pipeline(
    steps=[
        ("preprocessor", ct),
        (
            "classifier",
            SVC(
                random_state=19,
                # gamma="auto",
                class_weight=weights,
            ),
        ),
    ]
)

random_forest = Pipeline(
    steps=[
        ("preprocessor", ct),
        (
            "classifier",
            RandomForestClassifier(
                n_estimators=300,
                random_state=19,
                criterion="log_loss",
                class_weight=weights,
            ),
        ),
    ]
)

logistic_regression = Pipeline(
    steps=[
        ("preprocessor", ct),
        (
            "classifier",
            LogisticRegression(
                class_weight=weights,
                random_state=19,
                solver="newton-cholesky",
                max_iter=10_000,
            ),
        ),
    ]
)
In [22]:
svm
Out[22]:
Pipeline(steps=[('preprocessor',
                 ColumnTransformer(transformers=[('cat', OrdinalEncoder(),
                                                  ['job', 'marital',
                                                   'education', 'housing',
                                                   'loan', 'month',
                                                   'poutcome']),
                                                 ('num', MinMaxScaler(),
                                                  ['age', 'balance', 'campaign',
                                                   'pdays', 'previous'])])),
                ('classifier',
                 SVC(class_weight={'no': np.float64(0.5662397845758838),
                                   'yes': np.float64(4.27416686362562)},
                     random_state=19))])
In a Jupyter environment, please rerun this cell to show the HTML representation or trust the notebook.
On GitHub, the HTML representation is unable to render, please try loading this page with nbviewer.org.
Parameters
steps steps: list of tuples

List of (name of step, estimator) tuples that are to be chained in
sequential order. To be compatible with the scikit-learn API, all steps
must define `fit`. All non-last steps must also define `transform`. See
:ref:`Combining Estimators ` for more details. 		[('preprocessor', ...), ('classifier', ...)]
transform_input transform_input: list of str, default=None

The names of the :term:`metadata` parameters that should be transformed by the
pipeline before passing it to the step consuming it.

This enables transforming some input arguments to ``fit`` (other than ``X``)
to be transformed by the steps of the pipeline up to the step which requires
them. Requirement is defined via :ref:`metadata routing `.
For instance, this can be used to pass a validation set through the pipeline.

You can only set this if metadata routing is enabled, which you
can enable using ``sklearn.set_config(enable_metadata_routing=True)``.

.. versionadded:: 1.6 		None
memory memory: str or object with the joblib.Memory interface, default=None

Used to cache the fitted transformers of the pipeline. The last step
will never be cached, even if it is a transformer. By default, no
caching is performed. If a string is given, it is the path to the
caching directory. Enabling caching triggers a clone of the transformers
before fitting. Therefore, the transformer instance given to the
pipeline cannot be inspected directly. Use the attribute ``named_steps``
or ``steps`` to inspect estimators within the pipeline. Caching the
transformers is advantageous when fitting is time consuming. See
:ref:`sphx_glr_auto_examples_neighbors_plot_caching_nearest_neighbors.py`
for an example on how to enable caching. 		None
verbose verbose: bool, default=False

If True, the time elapsed while fitting each step will be printed as it
is completed. 		False
Parameters
transformers transformers: list of tuples

List of (name, transformer, columns) tuples specifying the
transformer objects to be applied to subsets of the data.

name : str
Like in Pipeline and FeatureUnion, this allows the transformer and
its parameters to be set using ``set_params`` and searched in grid
search.
transformer : {'drop', 'passthrough'} or estimator
Estimator must support :term:`fit` and :term:`transform`.
Special-cased strings 'drop' and 'passthrough' are accepted as
well, to indicate to drop the columns or to pass them through
untransformed, respectively.
columns : str, array-like of str, int, array-like of int, array-like of bool, slice or callable
Indexes the data on its second axis. Integers are interpreted as
positional columns, while strings can reference DataFrame columns
by name. A scalar string or int should be used where
``transformer`` expects X to be a 1d array-like (vector),
otherwise a 2d array will be passed to the transformer.
A callable is passed the input data `X` and can return any of the
above. To select multiple columns by name or dtype, you can use
:obj:`make_column_selector`. 		[('cat', ...), ('num', ...)]
remainder remainder: {'drop', 'passthrough'} or estimator, default='drop'

By default, only the specified columns in `transformers` are
transformed and combined in the output, and the non-specified
columns are dropped. (default of ``'drop'``).
By specifying ``remainder='passthrough'``, all remaining columns that
were not specified in `transformers`, but present in the data passed
to `fit` will be automatically passed through. This subset of columns
is concatenated with the output of the transformers. For dataframes,
extra columns not seen during `fit` will be excluded from the output
of `transform`.
By setting ``remainder`` to be an estimator, the remaining
non-specified columns will use the ``remainder`` estimator. The
estimator must support :term:`fit` and :term:`transform`.
Note that using this feature requires that the DataFrame columns
input at :term:`fit` and :term:`transform` have identical order. 		'drop'
sparse_threshold sparse_threshold: float, default=0.3

If the output of the different transformers contains sparse matrices,
these will be stacked as a sparse matrix if the overall density is
lower than this value. Use ``sparse_threshold=0`` to always return
dense. When the transformed output consists of all dense data, the
stacked result will be dense, and this keyword will be ignored. 		0.3
n_jobs n_jobs: int, default=None

Number of jobs to run in parallel.
``None`` means 1 unless in a :obj:`joblib.parallel_backend` context.
``-1`` means using all processors. See :term:`Glossary `
for more details. 		None
transformer_weights transformer_weights: dict, default=None

Multiplicative weights for features per transformer. The output of the
transformer is multiplied by these weights. Keys are transformer names,
values the weights. 		None
verbose verbose: bool, default=False

If True, the time elapsed while fitting each transformer will be
printed as it is completed. 		False
verbose_feature_names_out verbose_feature_names_out: bool, str or Callable[[str, str], str], default=True

- If True, :meth:`ColumnTransformer.get_feature_names_out` will prefix
all feature names with the name of the transformer that generated that
feature. It is equivalent to setting
`verbose_feature_names_out="{transformer_name}__{feature_name}"`.
- If False, :meth:`ColumnTransformer.get_feature_names_out` will not
prefix any feature names and will error if feature names are not
unique.
- If ``Callable[[str, str], str]``,
:meth:`ColumnTransformer.get_feature_names_out` will rename all the features
using the name of the transformer. The first argument of the callable is the
transformer name and the second argument is the feature name. The returned
string will be the new feature name.
- If ``str``, it must be a string ready for formatting. The given string will
be formatted using two field names: ``transformer_name`` and ``feature_name``.
e.g. ``"{feature_name}__{transformer_name}"``. See :meth:`str.format` method
from the standard library for more info.

.. versionadded:: 1.0

.. versionchanged:: 1.6
`verbose_feature_names_out` can be a callable or a string to be formatted. 		True
force_int_remainder_cols force_int_remainder_cols: bool, default=False

This parameter has no effect.

.. note::
If you do not access the list of columns for the remainder columns
in the `transformers_` fitted attribute, you do not need to set
this parameter.

.. versionadded:: 1.5

.. versionchanged:: 1.7
The default value for `force_int_remainder_cols` will change from
`True` to `False` in version 1.7.

.. deprecated:: 1.7
`force_int_remainder_cols` is deprecated and will be removed in 1.9. 		'deprecated'
['job', 'marital', 'education', 'housing', 'loan', 'month', 'poutcome']
Parameters
categories categories: 'auto' or a list of array-like, default='auto'

Categories (unique values) per feature:

- 'auto' : Determine categories automatically from the training data.
- list : ``categories[i]`` holds the categories expected in the ith
column. The passed categories should not mix strings and numeric
values, and should be sorted in case of numeric values.

The used categories can be found in the ``categories_`` attribute. 		'auto'
dtype dtype: number type, default=np.float64

Desired dtype of output. 		<class 'numpy.float64'>
handle_unknown handle_unknown: {'error', 'use_encoded_value'}, default='error'

When set to 'error' an error will be raised in case an unknown
categorical feature is present during transform. When set to
'use_encoded_value', the encoded value of unknown categories will be
set to the value given for the parameter `unknown_value`. In
:meth:`inverse_transform`, an unknown category will be denoted as None.

.. versionadded:: 0.24 		'error'
unknown_value unknown_value: int or np.nan, default=None

When the parameter handle_unknown is set to 'use_encoded_value', this
parameter is required and will set the encoded value of unknown
categories. It has to be distinct from the values used to encode any of
the categories in `fit`. If set to np.nan, the `dtype` parameter must
be a float dtype.

.. versionadded:: 0.24 		None
encoded_missing_value encoded_missing_value: int or np.nan, default=np.nan

Encoded value of missing categories. If set to `np.nan`, then the `dtype`
parameter must be a float dtype.

.. versionadded:: 1.1 		nan
min_frequency min_frequency: int or float, default=None

Specifies the minimum frequency below which a category will be
considered infrequent.

- If `int`, categories with a smaller cardinality will be considered
infrequent.

- If `float`, categories with a smaller cardinality than
`min_frequency * n_samples` will be considered infrequent.

.. versionadded:: 1.3
Read more in the :ref:`User Guide `. 		None
max_categories max_categories: int, default=None

Specifies an upper limit to the number of output categories for each input
feature when considering infrequent categories. If there are infrequent
categories, `max_categories` includes the category representing the
infrequent categories along with the frequent categories. If `None`,
there is no limit to the number of output features.

`max_categories` do **not** take into account missing or unknown
categories. Setting `unknown_value` or `encoded_missing_value` to an
integer will increase the number of unique integer codes by one each.
This can result in up to `max_categories + 2` integer codes.

.. versionadded:: 1.3
Read more in the :ref:`User Guide `. 		None
['age', 'balance', 'campaign', 'pdays', 'previous']
Parameters
feature_range feature_range: tuple (min, max), default=(0, 1)

Desired range of transformed data. 		(0, ...)
copy copy: bool, default=True

Set to False to perform inplace row normalization and avoid a
copy (if the input is already a numpy array). 		True
clip clip: bool, default=False

Set to True to clip transformed values of held-out data to
provided `feature_range`.
Since this parameter will clip values, `inverse_transform` may not
be able to restore the original data.

.. note::
Setting `clip=True` does not prevent feature drift (a distribution
shift between training and test data). The transformed values are clipped
to the `feature_range`, which helps avoid unintended behavior in models
sensitive to out-of-range inputs (e.g. linear models). Use with care,
as clipping can distort the distribution of test data.

.. versionadded:: 0.24 		False
Parameters
C C: float, default=1.0

Regularization parameter. The strength of the regularization is
inversely proportional to C. Must be strictly positive. The penalty
is a squared l2 penalty. For an intuitive visualization of the effects
of scaling the regularization parameter C, see
:ref:`sphx_glr_auto_examples_svm_plot_svm_scale_c.py`. 		1.0
kernel kernel: {'linear', 'poly', 'rbf', 'sigmoid', 'precomputed'} or callable, default='rbf'

Specifies the kernel type to be used in the algorithm. If
none is given, 'rbf' will be used. If a callable is given it is used to
pre-compute the kernel matrix from data matrices; that matrix should be
an array of shape ``(n_samples, n_samples)``. For an intuitive
visualization of different kernel types see
:ref:`sphx_glr_auto_examples_svm_plot_svm_kernels.py`. 		'rbf'
degree degree: int, default=3

Degree of the polynomial kernel function ('poly').
Must be non-negative. Ignored by all other kernels. 		3
gamma gamma: {'scale', 'auto'} or float, default='scale'

Kernel coefficient for 'rbf', 'poly' and 'sigmoid'.

- if ``gamma='scale'`` (default) is passed then it uses
1 / (n_features * X.var()) as value of gamma,
- if 'auto', uses 1 / n_features
- if float, must be non-negative.

.. versionchanged:: 0.22
The default value of ``gamma`` changed from 'auto' to 'scale'. 		'scale'
coef0 coef0: float, default=0.0

Independent term in kernel function.
It is only significant in 'poly' and 'sigmoid'. 		0.0
shrinking shrinking: bool, default=True

Whether to use the shrinking heuristic.
See the :ref:`User Guide `. 		True
probability probability: bool, default=False

Whether to enable probability estimates. This must be enabled prior
to calling `fit`, will slow down that method as it internally uses
5-fold cross-validation, and `predict_proba` may be inconsistent with
`predict`. Read more in the :ref:`User Guide `. 		False
tol tol: float, default=1e-3

Tolerance for stopping criterion. 		0.001
cache_size cache_size: float, default=200

Specify the size of the kernel cache (in MB). 		200
class_weight class_weight: dict or 'balanced', default=None

Set the parameter C of class i to class_weight[i]*C for
SVC. If not given, all classes are supposed to have
weight one.
The "balanced" mode uses the values of y to automatically adjust
weights inversely proportional to class frequencies in the input data
as ``n_samples / (n_classes * np.bincount(y))``. 		{'no': np.float64(0.5662397845758838), 'yes': np.float64(4.27416686362562)}
verbose verbose: bool, default=False

Enable verbose output. Note that this setting takes advantage of a
per-process runtime setting in libsvm that, if enabled, may not work
properly in a multithreaded context. 		False
max_iter max_iter: int, default=-1

Hard limit on iterations within solver, or -1 for no limit. 		-1
decision_function_shape decision_function_shape: {'ovo', 'ovr'}, default='ovr'

Whether to return a one-vs-rest ('ovr') decision function of shape
(n_samples, n_classes) as all other classifiers, or the original
one-vs-one ('ovo') decision function of libsvm which has shape
(n_samples, n_classes * (n_classes - 1) / 2). However, note that
internally, one-vs-one ('ovo') is always used as a multi-class strategy
to train models; an ovr matrix is only constructed from the ovo matrix.
The parameter is ignored for binary classification.

.. versionchanged:: 0.19
decision_function_shape is 'ovr' by default.

.. versionadded:: 0.17
*decision_function_shape='ovr'* is recommended.

.. versionchanged:: 0.17
Deprecated *decision_function_shape='ovo' and None*. 		'ovr'
break_ties break_ties: bool, default=False

If true, ``decision_function_shape='ovr'``, and number of classes > 2,
:term:`predict` will break ties according to the confidence values of
:term:`decision_function`; otherwise the first class among the tied
classes is returned. Please note that breaking ties comes at a
relatively high computational cost compared to a simple predict. See
:ref:`sphx_glr_auto_examples_svm_plot_svm_tie_breaking.py` for an
example of its usage with ``decision_function_shape='ovr'``.

.. versionadded:: 0.22 		False
random_state random_state: int, RandomState instance or None, default=None

Controls the pseudo random number generation for shuffling the data for
probability estimates. Ignored when `probability` is False.
Pass an int for reproducible output across multiple function calls.
See :term:`Glossary `. 		19
In [23]:
random_forest
Out[23]:
Pipeline(steps=[('preprocessor',
                 ColumnTransformer(transformers=[('cat', OrdinalEncoder(),
                                                  ['job', 'marital',
                                                   'education', 'housing',
                                                   'loan', 'month',
                                                   'poutcome']),
                                                 ('num', MinMaxScaler(),
                                                  ['age', 'balance', 'campaign',
                                                   'pdays', 'previous'])])),
                ('classifier',
                 RandomForestClassifier(class_weight={'no': np.float64(0.5662397845758838),
                                                      'yes': np.float64(4.27416686362562)},
                                        criterion='log_loss', n_estimators=300,
                                        random_state=19))])
In a Jupyter environment, please rerun this cell to show the HTML representation or trust the notebook.
On GitHub, the HTML representation is unable to render, please try loading this page with nbviewer.org.
Parameters
steps steps: list of tuples

List of (name of step, estimator) tuples that are to be chained in
sequential order. To be compatible with the scikit-learn API, all steps
must define `fit`. All non-last steps must also define `transform`. See
:ref:`Combining Estimators ` for more details. 		[('preprocessor', ...), ('classifier', ...)]
transform_input transform_input: list of str, default=None

The names of the :term:`metadata` parameters that should be transformed by the
pipeline before passing it to the step consuming it.

This enables transforming some input arguments to ``fit`` (other than ``X``)
to be transformed by the steps of the pipeline up to the step which requires
them. Requirement is defined via :ref:`metadata routing `.
For instance, this can be used to pass a validation set through the pipeline.

You can only set this if metadata routing is enabled, which you
can enable using ``sklearn.set_config(enable_metadata_routing=True)``.

.. versionadded:: 1.6 		None
memory memory: str or object with the joblib.Memory interface, default=None

Used to cache the fitted transformers of the pipeline. The last step
will never be cached, even if it is a transformer. By default, no
caching is performed. If a string is given, it is the path to the
caching directory. Enabling caching triggers a clone of the transformers
before fitting. Therefore, the transformer instance given to the
pipeline cannot be inspected directly. Use the attribute ``named_steps``
or ``steps`` to inspect estimators within the pipeline. Caching the
transformers is advantageous when fitting is time consuming. See
:ref:`sphx_glr_auto_examples_neighbors_plot_caching_nearest_neighbors.py`
for an example on how to enable caching. 		None
verbose verbose: bool, default=False

If True, the time elapsed while fitting each step will be printed as it
is completed. 		False
Parameters
transformers transformers: list of tuples

List of (name, transformer, columns) tuples specifying the
transformer objects to be applied to subsets of the data.

name : str
Like in Pipeline and FeatureUnion, this allows the transformer and
its parameters to be set using ``set_params`` and searched in grid
search.
transformer : {'drop', 'passthrough'} or estimator
Estimator must support :term:`fit` and :term:`transform`.
Special-cased strings 'drop' and 'passthrough' are accepted as
well, to indicate to drop the columns or to pass them through
untransformed, respectively.
columns : str, array-like of str, int, array-like of int, array-like of bool, slice or callable
Indexes the data on its second axis. Integers are interpreted as
positional columns, while strings can reference DataFrame columns
by name. A scalar string or int should be used where
``transformer`` expects X to be a 1d array-like (vector),
otherwise a 2d array will be passed to the transformer.
A callable is passed the input data `X` and can return any of the
above. To select multiple columns by name or dtype, you can use
:obj:`make_column_selector`. 		[('cat', ...), ('num', ...)]
remainder remainder: {'drop', 'passthrough'} or estimator, default='drop'

By default, only the specified columns in `transformers` are
transformed and combined in the output, and the non-specified
columns are dropped. (default of ``'drop'``).
By specifying ``remainder='passthrough'``, all remaining columns that
were not specified in `transformers`, but present in the data passed
to `fit` will be automatically passed through. This subset of columns
is concatenated with the output of the transformers. For dataframes,
extra columns not seen during `fit` will be excluded from the output
of `transform`.
By setting ``remainder`` to be an estimator, the remaining
non-specified columns will use the ``remainder`` estimator. The
estimator must support :term:`fit` and :term:`transform`.
Note that using this feature requires that the DataFrame columns
input at :term:`fit` and :term:`transform` have identical order. 		'drop'
sparse_threshold sparse_threshold: float, default=0.3

If the output of the different transformers contains sparse matrices,
these will be stacked as a sparse matrix if the overall density is
lower than this value. Use ``sparse_threshold=0`` to always return
dense. When the transformed output consists of all dense data, the
stacked result will be dense, and this keyword will be ignored. 		0.3
n_jobs n_jobs: int, default=None

Number of jobs to run in parallel.
``None`` means 1 unless in a :obj:`joblib.parallel_backend` context.
``-1`` means using all processors. See :term:`Glossary `
for more details. 		None
transformer_weights transformer_weights: dict, default=None

Multiplicative weights for features per transformer. The output of the
transformer is multiplied by these weights. Keys are transformer names,
values the weights. 		None
verbose verbose: bool, default=False

If True, the time elapsed while fitting each transformer will be
printed as it is completed. 		False
verbose_feature_names_out verbose_feature_names_out: bool, str or Callable[[str, str], str], default=True

- If True, :meth:`ColumnTransformer.get_feature_names_out` will prefix
all feature names with the name of the transformer that generated that
feature. It is equivalent to setting
`verbose_feature_names_out="{transformer_name}__{feature_name}"`.
- If False, :meth:`ColumnTransformer.get_feature_names_out` will not
prefix any feature names and will error if feature names are not
unique.
- If ``Callable[[str, str], str]``,
:meth:`ColumnTransformer.get_feature_names_out` will rename all the features
using the name of the transformer. The first argument of the callable is the
transformer name and the second argument is the feature name. The returned
string will be the new feature name.
- If ``str``, it must be a string ready for formatting. The given string will
be formatted using two field names: ``transformer_name`` and ``feature_name``.
e.g. ``"{feature_name}__{transformer_name}"``. See :meth:`str.format` method
from the standard library for more info.

.. versionadded:: 1.0

.. versionchanged:: 1.6
`verbose_feature_names_out` can be a callable or a string to be formatted. 		True
force_int_remainder_cols force_int_remainder_cols: bool, default=False

This parameter has no effect.

.. note::
If you do not access the list of columns for the remainder columns
in the `transformers_` fitted attribute, you do not need to set
this parameter.

.. versionadded:: 1.5

.. versionchanged:: 1.7
The default value for `force_int_remainder_cols` will change from
`True` to `False` in version 1.7.

.. deprecated:: 1.7
`force_int_remainder_cols` is deprecated and will be removed in 1.9. 		'deprecated'
['job', 'marital', 'education', 'housing', 'loan', 'month', 'poutcome']
Parameters
categories categories: 'auto' or a list of array-like, default='auto'

Categories (unique values) per feature:

- 'auto' : Determine categories automatically from the training data.
- list : ``categories[i]`` holds the categories expected in the ith
column. The passed categories should not mix strings and numeric
values, and should be sorted in case of numeric values.

The used categories can be found in the ``categories_`` attribute. 		'auto'
dtype dtype: number type, default=np.float64

Desired dtype of output. 		<class 'numpy.float64'>
handle_unknown handle_unknown: {'error', 'use_encoded_value'}, default='error'

When set to 'error' an error will be raised in case an unknown
categorical feature is present during transform. When set to
'use_encoded_value', the encoded value of unknown categories will be
set to the value given for the parameter `unknown_value`. In
:meth:`inverse_transform`, an unknown category will be denoted as None.

.. versionadded:: 0.24 		'error'
unknown_value unknown_value: int or np.nan, default=None

When the parameter handle_unknown is set to 'use_encoded_value', this
parameter is required and will set the encoded value of unknown
categories. It has to be distinct from the values used to encode any of
the categories in `fit`. If set to np.nan, the `dtype` parameter must
be a float dtype.

.. versionadded:: 0.24 		None
encoded_missing_value encoded_missing_value: int or np.nan, default=np.nan

Encoded value of missing categories. If set to `np.nan`, then the `dtype`
parameter must be a float dtype.

.. versionadded:: 1.1 		nan
min_frequency min_frequency: int or float, default=None

Specifies the minimum frequency below which a category will be
considered infrequent.

- If `int`, categories with a smaller cardinality will be considered
infrequent.

- If `float`, categories with a smaller cardinality than
`min_frequency * n_samples` will be considered infrequent.

.. versionadded:: 1.3
Read more in the :ref:`User Guide `. 		None
max_categories max_categories: int, default=None

Specifies an upper limit to the number of output categories for each input
feature when considering infrequent categories. If there are infrequent
categories, `max_categories` includes the category representing the
infrequent categories along with the frequent categories. If `None`,
there is no limit to the number of output features.

`max_categories` do **not** take into account missing or unknown
categories. Setting `unknown_value` or `encoded_missing_value` to an
integer will increase the number of unique integer codes by one each.
This can result in up to `max_categories + 2` integer codes.

.. versionadded:: 1.3
Read more in the :ref:`User Guide `. 		None
['age', 'balance', 'campaign', 'pdays', 'previous']
Parameters
feature_range feature_range: tuple (min, max), default=(0, 1)

Desired range of transformed data. 		(0, ...)
copy copy: bool, default=True

Set to False to perform inplace row normalization and avoid a
copy (if the input is already a numpy array). 		True
clip clip: bool, default=False

Set to True to clip transformed values of held-out data to
provided `feature_range`.
Since this parameter will clip values, `inverse_transform` may not
be able to restore the original data.

.. note::
Setting `clip=True` does not prevent feature drift (a distribution
shift between training and test data). The transformed values are clipped
to the `feature_range`, which helps avoid unintended behavior in models
sensitive to out-of-range inputs (e.g. linear models). Use with care,
as clipping can distort the distribution of test data.

.. versionadded:: 0.24 		False
Parameters
n_estimators n_estimators: int, default=100

The number of trees in the forest.

.. versionchanged:: 0.22
The default value of ``n_estimators`` changed from 10 to 100
in 0.22. 		300
criterion criterion: {"gini", "entropy", "log_loss"}, default="gini"

The function to measure the quality of a split. Supported criteria are
"gini" for the Gini impurity and "log_loss" and "entropy" both for the
Shannon information gain, see :ref:`tree_mathematical_formulation`.
Note: This parameter is tree-specific. 		'log_loss'
max_depth max_depth: int, default=None

The maximum depth of the tree. If None, then nodes are expanded until
all leaves are pure or until all leaves contain less than
min_samples_split samples. 		None
min_samples_split min_samples_split: int or float, default=2

The minimum number of samples required to split an internal node:

- If int, then consider `min_samples_split` as the minimum number.
- If float, then `min_samples_split` is a fraction and
`ceil(min_samples_split * n_samples)` are the minimum
number of samples for each split.

.. versionchanged:: 0.18
Added float values for fractions. 		2
min_samples_leaf min_samples_leaf: int or float, default=1

The minimum number of samples required to be at a leaf node.
A split point at any depth will only be considered if it leaves at
least ``min_samples_leaf`` training samples in each of the left and
right branches. This may have the effect of smoothing the model,
especially in regression.

- If int, then consider `min_samples_leaf` as the minimum number.
- If float, then `min_samples_leaf` is a fraction and
`ceil(min_samples_leaf * n_samples)` are the minimum
number of samples for each node.

.. versionchanged:: 0.18
Added float values for fractions. 		1
min_weight_fraction_leaf min_weight_fraction_leaf: float, default=0.0

The minimum weighted fraction of the sum total of weights (of all
the input samples) required to be at a leaf node. Samples have
equal weight when sample_weight is not provided. 		0.0
max_features max_features: {"sqrt", "log2", None}, int or float, default="sqrt"

The number of features to consider when looking for the best split:

- If int, then consider `max_features` features at each split.
- If float, then `max_features` is a fraction and
`max(1, int(max_features * n_features_in_))` features are considered at each
split.
- If "sqrt", then `max_features=sqrt(n_features)`.
- If "log2", then `max_features=log2(n_features)`.
- If None, then `max_features=n_features`.

.. versionchanged:: 1.1
The default of `max_features` changed from `"auto"` to `"sqrt"`.

Note: the search for a split does not stop until at least one
valid partition of the node samples is found, even if it requires to
effectively inspect more than ``max_features`` features. 		'sqrt'
max_leaf_nodes max_leaf_nodes: int, default=None

Grow trees with ``max_leaf_nodes`` in best-first fashion.
Best nodes are defined as relative reduction in impurity.
If None then unlimited number of leaf nodes. 		None
min_impurity_decrease min_impurity_decrease: float, default=0.0

A node will be split if this split induces a decrease of the impurity
greater than or equal to this value.

The weighted impurity decrease equation is the following::

N_t / N * (impurity - N_t_R / N_t * right_impurity
- N_t_L / N_t * left_impurity)

where ``N`` is the total number of samples, ``N_t`` is the number of
samples at the current node, ``N_t_L`` is the number of samples in the
left child, and ``N_t_R`` is the number of samples in the right child.

``N``, ``N_t``, ``N_t_R`` and ``N_t_L`` all refer to the weighted sum,
if ``sample_weight`` is passed.

.. versionadded:: 0.19 		0.0
bootstrap bootstrap: bool, default=True

Whether bootstrap samples are used when building trees. If False, the
whole dataset is used to build each tree. 		True
oob_score oob_score: bool or callable, default=False

Whether to use out-of-bag samples to estimate the generalization score.
By default, :func:`~sklearn.metrics.accuracy_score` is used.
Provide a callable with signature `metric(y_true, y_pred)` to use a
custom metric. Only available if `bootstrap=True`.

For an illustration of out-of-bag (OOB) error estimation, see the example
:ref:`sphx_glr_auto_examples_ensemble_plot_ensemble_oob.py`. 		False
n_jobs n_jobs: int, default=None

The number of jobs to run in parallel. :meth:`fit`, :meth:`predict`,
:meth:`decision_path` and :meth:`apply` are all parallelized over the
trees. ``None`` means 1 unless in a :obj:`joblib.parallel_backend`
context. ``-1`` means using all processors. See :term:`Glossary
` for more details. 		None
random_state random_state: int, RandomState instance or None, default=None

Controls both the randomness of the bootstrapping of the samples used
when building trees (if ``bootstrap=True``) and the sampling of the
features to consider when looking for the best split at each node
(if ``max_features < n_features``).
See :term:`Glossary ` for details. 		19
verbose verbose: int, default=0

Controls the verbosity when fitting and predicting. 		0
warm_start warm_start: bool, default=False

When set to ``True``, reuse the solution of the previous call to fit
and add more estimators to the ensemble, otherwise, just fit a whole
new forest. See :term:`Glossary ` and
:ref:`tree_ensemble_warm_start` for details. 		False
class_weight class_weight: {"balanced", "balanced_subsample"}, dict or list of dicts, default=None

Weights associated with classes in the form ``{class_label: weight}``.
If not given, all classes are supposed to have weight one. For
multi-output problems, a list of dicts can be provided in the same
order as the columns of y.

Note that for multioutput (including multilabel) weights should be
defined for each class of every column in its own dict. For example,
for four-class multilabel classification weights should be
[{0: 1, 1: 1}, {0: 1, 1: 5}, {0: 1, 1: 1}, {0: 1, 1: 1}] instead of
[{1:1}, {2:5}, {3:1}, {4:1}].

The "balanced" mode uses the values of y to automatically adjust
weights inversely proportional to class frequencies in the input data
as ``n_samples / (n_classes * np.bincount(y))``

The "balanced_subsample" mode is the same as "balanced" except that
weights are computed based on the bootstrap sample for every tree
grown.

For multi-output, the weights of each column of y will be multiplied.

Note that these weights will be multiplied with sample_weight (passed
through the fit method) if sample_weight is specified. 		{'no': np.float64(0.5662397845758838), 'yes': np.float64(4.27416686362562)}
ccp_alpha ccp_alpha: non-negative float, default=0.0

Complexity parameter used for Minimal Cost-Complexity Pruning. The
subtree with the largest cost complexity that is smaller than
``ccp_alpha`` will be chosen. By default, no pruning is performed. See
:ref:`minimal_cost_complexity_pruning` for details. See
:ref:`sphx_glr_auto_examples_tree_plot_cost_complexity_pruning.py`
for an example of such pruning.

.. versionadded:: 0.22 		0.0
max_samples max_samples: int or float, default=None

If bootstrap is True, the number of samples to draw from X
to train each base estimator.

- If None (default), then draw `X.shape[0]` samples.
- If int, then draw `max_samples` samples.
- If float, then draw `max(round(n_samples * max_samples), 1)` samples. Thus,
`max_samples` should be in the interval `(0.0, 1.0]`.

.. versionadded:: 0.22 		None
monotonic_cst monotonic_cst: array-like of int of shape (n_features), default=None

Indicates the monotonicity constraint to enforce on each feature.
- 1: monotonic increase
- 0: no constraint
- -1: monotonic decrease

If monotonic_cst is None, no constraints are applied.

Monotonicity constraints are not supported for:
- multiclass classifications (i.e. when `n_classes > 2`),
- multioutput classifications (i.e. when `n_outputs_ > 1`),
- classifications trained on data with missing values.

The constraints hold over the probability of the positive class.

Read more in the :ref:`User Guide `.

.. versionadded:: 1.4 		None
In [24]:
logistic_regression
Out[24]:
Pipeline(steps=[('preprocessor',
                 ColumnTransformer(transformers=[('cat', OrdinalEncoder(),
                                                  ['job', 'marital',
                                                   'education', 'housing',
                                                   'loan', 'month',
                                                   'poutcome']),
                                                 ('num', MinMaxScaler(),
                                                  ['age', 'balance', 'campaign',
                                                   'pdays', 'previous'])])),
                ('classifier',
                 LogisticRegression(class_weight={'no': np.float64(0.5662397845758838),
                                                  'yes': np.float64(4.27416686362562)},
                                    max_iter=10000, random_state=19,
                                    solver='newton-cholesky'))])
In a Jupyter environment, please rerun this cell to show the HTML representation or trust the notebook.
On GitHub, the HTML representation is unable to render, please try loading this page with nbviewer.org.
Parameters
steps steps: list of tuples

List of (name of step, estimator) tuples that are to be chained in
sequential order. To be compatible with the scikit-learn API, all steps
must define `fit`. All non-last steps must also define `transform`. See
:ref:`Combining Estimators ` for more details. 		[('preprocessor', ...), ('classifier', ...)]
transform_input transform_input: list of str, default=None

The names of the :term:`metadata` parameters that should be transformed by the
pipeline before passing it to the step consuming it.

This enables transforming some input arguments to ``fit`` (other than ``X``)
to be transformed by the steps of the pipeline up to the step which requires
them. Requirement is defined via :ref:`metadata routing `.
For instance, this can be used to pass a validation set through the pipeline.

You can only set this if metadata routing is enabled, which you
can enable using ``sklearn.set_config(enable_metadata_routing=True)``.

.. versionadded:: 1.6 		None
memory memory: str or object with the joblib.Memory interface, default=None

Used to cache the fitted transformers of the pipeline. The last step
will never be cached, even if it is a transformer. By default, no
caching is performed. If a string is given, it is the path to the
caching directory. Enabling caching triggers a clone of the transformers
before fitting. Therefore, the transformer instance given to the
pipeline cannot be inspected directly. Use the attribute ``named_steps``
or ``steps`` to inspect estimators within the pipeline. Caching the
transformers is advantageous when fitting is time consuming. See
:ref:`sphx_glr_auto_examples_neighbors_plot_caching_nearest_neighbors.py`
for an example on how to enable caching. 		None
verbose verbose: bool, default=False

If True, the time elapsed while fitting each step will be printed as it
is completed. 		False
Parameters
transformers transformers: list of tuples

List of (name, transformer, columns) tuples specifying the
transformer objects to be applied to subsets of the data.

name : str
Like in Pipeline and FeatureUnion, this allows the transformer and
its parameters to be set using ``set_params`` and searched in grid
search.
transformer : {'drop', 'passthrough'} or estimator
Estimator must support :term:`fit` and :term:`transform`.
Special-cased strings 'drop' and 'passthrough' are accepted as
well, to indicate to drop the columns or to pass them through
untransformed, respectively.
columns : str, array-like of str, int, array-like of int, array-like of bool, slice or callable
Indexes the data on its second axis. Integers are interpreted as
positional columns, while strings can reference DataFrame columns
by name. A scalar string or int should be used where
``transformer`` expects X to be a 1d array-like (vector),
otherwise a 2d array will be passed to the transformer.
A callable is passed the input data `X` and can return any of the
above. To select multiple columns by name or dtype, you can use
:obj:`make_column_selector`. 		[('cat', ...), ('num', ...)]
remainder remainder: {'drop', 'passthrough'} or estimator, default='drop'

By default, only the specified columns in `transformers` are
transformed and combined in the output, and the non-specified
columns are dropped. (default of ``'drop'``).
By specifying ``remainder='passthrough'``, all remaining columns that
were not specified in `transformers`, but present in the data passed
to `fit` will be automatically passed through. This subset of columns
is concatenated with the output of the transformers. For dataframes,
extra columns not seen during `fit` will be excluded from the output
of `transform`.
By setting ``remainder`` to be an estimator, the remaining
non-specified columns will use the ``remainder`` estimator. The
estimator must support :term:`fit` and :term:`transform`.
Note that using this feature requires that the DataFrame columns
input at :term:`fit` and :term:`transform` have identical order. 		'drop'
sparse_threshold sparse_threshold: float, default=0.3

If the output of the different transformers contains sparse matrices,
these will be stacked as a sparse matrix if the overall density is
lower than this value. Use ``sparse_threshold=0`` to always return
dense. When the transformed output consists of all dense data, the
stacked result will be dense, and this keyword will be ignored. 		0.3
n_jobs n_jobs: int, default=None

Number of jobs to run in parallel.
``None`` means 1 unless in a :obj:`joblib.parallel_backend` context.
``-1`` means using all processors. See :term:`Glossary `
for more details. 		None
transformer_weights transformer_weights: dict, default=None

Multiplicative weights for features per transformer. The output of the
transformer is multiplied by these weights. Keys are transformer names,
values the weights. 		None
verbose verbose: bool, default=False

If True, the time elapsed while fitting each transformer will be
printed as it is completed. 		False
verbose_feature_names_out verbose_feature_names_out: bool, str or Callable[[str, str], str], default=True

- If True, :meth:`ColumnTransformer.get_feature_names_out` will prefix
all feature names with the name of the transformer that generated that
feature. It is equivalent to setting
`verbose_feature_names_out="{transformer_name}__{feature_name}"`.
- If False, :meth:`ColumnTransformer.get_feature_names_out` will not
prefix any feature names and will error if feature names are not
unique.
- If ``Callable[[str, str], str]``,
:meth:`ColumnTransformer.get_feature_names_out` will rename all the features
using the name of the transformer. The first argument of the callable is the
transformer name and the second argument is the feature name. The returned
string will be the new feature name.
- If ``str``, it must be a string ready for formatting. The given string will
be formatted using two field names: ``transformer_name`` and ``feature_name``.
e.g. ``"{feature_name}__{transformer_name}"``. See :meth:`str.format` method
from the standard library for more info.

.. versionadded:: 1.0

.. versionchanged:: 1.6
`verbose_feature_names_out` can be a callable or a string to be formatted. 		True
force_int_remainder_cols force_int_remainder_cols: bool, default=False

This parameter has no effect.

.. note::
If you do not access the list of columns for the remainder columns
in the `transformers_` fitted attribute, you do not need to set
this parameter.

.. versionadded:: 1.5

.. versionchanged:: 1.7
The default value for `force_int_remainder_cols` will change from
`True` to `False` in version 1.7.

.. deprecated:: 1.7
`force_int_remainder_cols` is deprecated and will be removed in 1.9. 		'deprecated'
['job', 'marital', 'education', 'housing', 'loan', 'month', 'poutcome']
Parameters
categories categories: 'auto' or a list of array-like, default='auto'

Categories (unique values) per feature:

- 'auto' : Determine categories automatically from the training data.
- list : ``categories[i]`` holds the categories expected in the ith
column. The passed categories should not mix strings and numeric
values, and should be sorted in case of numeric values.

The used categories can be found in the ``categories_`` attribute. 		'auto'
dtype dtype: number type, default=np.float64

Desired dtype of output. 		<class 'numpy.float64'>
handle_unknown handle_unknown: {'error', 'use_encoded_value'}, default='error'

When set to 'error' an error will be raised in case an unknown
categorical feature is present during transform. When set to
'use_encoded_value', the encoded value of unknown categories will be
set to the value given for the parameter `unknown_value`. In
:meth:`inverse_transform`, an unknown category will be denoted as None.

.. versionadded:: 0.24 		'error'
unknown_value unknown_value: int or np.nan, default=None

When the parameter handle_unknown is set to 'use_encoded_value', this
parameter is required and will set the encoded value of unknown
categories. It has to be distinct from the values used to encode any of
the categories in `fit`. If set to np.nan, the `dtype` parameter must
be a float dtype.

.. versionadded:: 0.24 		None
encoded_missing_value encoded_missing_value: int or np.nan, default=np.nan

Encoded value of missing categories. If set to `np.nan`, then the `dtype`
parameter must be a float dtype.

.. versionadded:: 1.1 		nan
min_frequency min_frequency: int or float, default=None

Specifies the minimum frequency below which a category will be
considered infrequent.

- If `int`, categories with a smaller cardinality will be considered
infrequent.

- If `float`, categories with a smaller cardinality than
`min_frequency * n_samples` will be considered infrequent.

.. versionadded:: 1.3
Read more in the :ref:`User Guide `. 		None
max_categories max_categories: int, default=None

Specifies an upper limit to the number of output categories for each input
feature when considering infrequent categories. If there are infrequent
categories, `max_categories` includes the category representing the
infrequent categories along with the frequent categories. If `None`,
there is no limit to the number of output features.

`max_categories` do **not** take into account missing or unknown
categories. Setting `unknown_value` or `encoded_missing_value` to an
integer will increase the number of unique integer codes by one each.
This can result in up to `max_categories + 2` integer codes.

.. versionadded:: 1.3
Read more in the :ref:`User Guide `. 		None
['age', 'balance', 'campaign', 'pdays', 'previous']
Parameters
feature_range feature_range: tuple (min, max), default=(0, 1)

Desired range of transformed data. 		(0, ...)
copy copy: bool, default=True

Set to False to perform inplace row normalization and avoid a
copy (if the input is already a numpy array). 		True
clip clip: bool, default=False

Set to True to clip transformed values of held-out data to
provided `feature_range`.
Since this parameter will clip values, `inverse_transform` may not
be able to restore the original data.

.. note::
Setting `clip=True` does not prevent feature drift (a distribution
shift between training and test data). The transformed values are clipped
to the `feature_range`, which helps avoid unintended behavior in models
sensitive to out-of-range inputs (e.g. linear models). Use with care,
as clipping can distort the distribution of test data.

.. versionadded:: 0.24 		False
Parameters
penalty penalty: {'l1', 'l2', 'elasticnet', None}, default='l2'

Specify the norm of the penalty:

- `None`: no penalty is added;
- `'l2'`: add a L2 penalty term and it is the default choice;
- `'l1'`: add a L1 penalty term;
- `'elasticnet'`: both L1 and L2 penalty terms are added.

.. warning::
Some penalties may not work with some solvers. See the parameter
`solver` below, to know the compatibility between the penalty and
solver.

.. versionadded:: 0.19
l1 penalty with SAGA solver (allowing 'multinomial' + L1)

.. deprecated:: 1.8
`penalty` was deprecated in version 1.8 and will be removed in 1.10.
Use `l1_ratio` instead. `l1_ratio=0` for `penalty='l2'`, `l1_ratio=1` for
`penalty='l1'` and `l1_ratio` set to any float between 0 and 1 for
`'penalty='elasticnet'`. 		'deprecated'
C C: float, default=1.0

Inverse of regularization strength; must be a positive float.
Like in support vector machines, smaller values specify stronger
regularization. `C=np.inf` results in unpenalized logistic regression.
For a visual example on the effect of tuning the `C` parameter
with an L1 penalty, see:
:ref:`sphx_glr_auto_examples_linear_model_plot_logistic_path.py`. 		1.0
l1_ratio l1_ratio: float, default=0.0

The Elastic-Net mixing parameter, with `0 <= l1_ratio <= 1`. Setting
`l1_ratio=1` gives a pure L1-penalty, setting `l1_ratio=0` a pure L2-penalty.
Any value between 0 and 1 gives an Elastic-Net penalty of the form
`l1_ratio * L1 + (1 - l1_ratio) * L2`.

.. warning::
Certain values of `l1_ratio`, i.e. some penalties, may not work with some
solvers. See the parameter `solver` below, to know the compatibility between
the penalty and solver.

.. versionchanged:: 1.8
Default value changed from None to 0.0.

.. deprecated:: 1.8
`None` is deprecated and will be removed in version 1.10. Always use
`l1_ratio` to specify the penalty type. 		0.0
dual dual: bool, default=False

Dual (constrained) or primal (regularized, see also
:ref:`this equation `) formulation. Dual formulation
is only implemented for l2 penalty with liblinear solver. Prefer `dual=False`
when n_samples > n_features. 		False
tol tol: float, default=1e-4

Tolerance for stopping criteria. 		0.0001
fit_intercept fit_intercept: bool, default=True

Specifies if a constant (a.k.a. bias or intercept) should be
added to the decision function. 		True
intercept_scaling intercept_scaling: float, default=1

Useful only when the solver `liblinear` is used
and `self.fit_intercept` is set to `True`. In this case, `x` becomes
`[x, self.intercept_scaling]`,
i.e. a "synthetic" feature with constant value equal to
`intercept_scaling` is appended to the instance vector.
The intercept becomes
``intercept_scaling * synthetic_feature_weight``.

.. note::
The synthetic feature weight is subject to L1 or L2
regularization as all other features.
To lessen the effect of regularization on synthetic feature weight
(and therefore on the intercept) `intercept_scaling` has to be increased. 		1
class_weight class_weight: dict or 'balanced', default=None

Weights associated with classes in the form ``{class_label: weight}``.
If not given, all classes are supposed to have weight one.

The "balanced" mode uses the values of y to automatically adjust
weights inversely proportional to class frequencies in the input data
as ``n_samples / (n_classes * np.bincount(y))``.

Note that these weights will be multiplied with sample_weight (passed
through the fit method) if sample_weight is specified.

.. versionadded:: 0.17
*class_weight='balanced'* 		{'no': np.float64(0.5662397845758838), 'yes': np.float64(4.27416686362562)}
random_state random_state: int, RandomState instance, default=None

Used when ``solver`` == 'sag', 'saga' or 'liblinear' to shuffle the
data. See :term:`Glossary ` for details. 		19
solver solver: {'lbfgs', 'liblinear', 'newton-cg', 'newton-cholesky', 'sag', 'saga'}, default='lbfgs'

Algorithm to use in the optimization problem. Default is 'lbfgs'.
To choose a solver, you might want to consider the following aspects:

- 'lbfgs' is a good default solver because it works reasonably well for a wide
class of problems.
- For :term:`multiclass` problems (`n_classes >= 3`), all solvers except
'liblinear' minimize the full multinomial loss, 'liblinear' will raise an
error.
- 'newton-cholesky' is a good choice for
`n_samples` >> `n_features * n_classes`, especially with one-hot encoded
categorical features with rare categories. Be aware that the memory usage
of this solver has a quadratic dependency on `n_features * n_classes`
because it explicitly computes the full Hessian matrix.
- For small datasets, 'liblinear' is a good choice, whereas 'sag'
and 'saga' are faster for large ones;
- 'liblinear' can only handle binary classification by default. To apply a
one-versus-rest scheme for the multiclass setting one can wrap it with the
:class:`~sklearn.multiclass.OneVsRestClassifier`.

.. warning::
The choice of the algorithm depends on the penalty chosen (`l1_ratio=0`
for L2-penalty, `l1_ratio=1` for L1-penalty and `0 < l1_ratio < 1` for
Elastic-Net) and on (multinomial) multiclass support:

================= ======================== ======================
solver l1_ratio multinomial multiclass
================= ======================== ======================
'lbfgs' l1_ratio=0 yes
'liblinear' l1_ratio=1 or l1_ratio=0 no
'newton-cg' l1_ratio=0 yes
'newton-cholesky' l1_ratio=0 yes
'sag' l1_ratio=0 yes
'saga' 0<=l1_ratio<=1 yes
================= ======================== ======================

.. note::
'sag' and 'saga' fast convergence is only guaranteed on features
with approximately the same scale. You can preprocess the data with
a scaler from :mod:`sklearn.preprocessing`.

.. seealso::
Refer to the :ref:`User Guide ` for more
information regarding :class:`LogisticRegression` and more specifically the
:ref:`Table `
summarizing solver/penalty supports.

.. versionadded:: 0.17
Stochastic Average Gradient (SAG) descent solver. Multinomial support in
version 0.18.
.. versionadded:: 0.19
SAGA solver.
.. versionchanged:: 0.22
The default solver changed from 'liblinear' to 'lbfgs' in 0.22.
.. versionadded:: 1.2
newton-cholesky solver. Multinomial support in version 1.6. 		'newton-cholesky'
max_iter max_iter: int, default=100

Maximum number of iterations taken for the solvers to converge. 		10000
verbose verbose: int, default=0

For the liblinear and lbfgs solvers set verbose to any positive
number for verbosity. 		0
warm_start warm_start: bool, default=False

When set to True, reuse the solution of the previous call to fit as
initialization, otherwise, just erase the previous solution.
Useless for liblinear solver. See :term:`the Glossary `.

.. versionadded:: 0.17
*warm_start* to support *lbfgs*, *newton-cg*, *sag*, *saga* solvers. 		False
n_jobs n_jobs: int, default=None

Does not have any effect.

.. deprecated:: 1.8
`n_jobs` is deprecated in version 1.8 and will be removed in 1.10. 		None
In [25]:
from tqdm import tqdm

predictions = []

for _model in tqdm([svm, random_forest, logistic_regression], desc="Training Model", unit="model"):
    _model.fit(X_train, y_train)
    predictions.append(_model.predict(X_test))

Markdown("### Training Complete")

Training Model: 100%|███████████████████████████████████████████████| 3/3 [00:28<00:00,  9.53s/model]
Out[25]:

Training Complete¶

In [26]:
from sklearn.metrics import classification_report

_reports = []

for _name, _preds in tqdm(zip(["SVM", "Random Forest", "Logistic Regression"], predictions), desc='Predicting...'):
    _reports.append(
        pd.DataFrame(
            classification_report(
                y_test,
                _preds,
                output_dict=True,
            )
        )
    )

for _name, _report in zip(["SVM", "Random Forest", "Logistic Regression"], _reports):
    display(Markdown(f"### Classification Report for {_name}"))
    display(_report)
    display()

Predicting...: 3it [00:00, 27.29it/s]

Classification Report for SVM¶

no yes accuracy macro avg weighted avg
precision 0.930701 0.216060 0.698441 0.573381 0.847091
recall 0.711459 0.600189 0.698441 0.655824 0.698441
f1-score 0.806445 0.317738 0.698441 0.562092 0.749268
support 7985.000000 1058.000000 0.698441 9043.000000 9043.000000

Classification Report for Random Forest¶

no yes accuracy macro avg weighted avg
precision 0.904372 0.612299 0.892292 0.758336 0.870200
recall 0.981841 0.216446 0.892292 0.599144 0.892292
f1-score 0.941516 0.319832 0.892292 0.630674 0.868781
support 7985.000000 1058.000000 0.892292 9043.000000 9043.000000

Classification Report for Logistic Regression¶

no yes accuracy macro avg weighted avg
precision 0.933299 0.207688 0.674444 0.570493 0.848405
recall 0.679900 0.633270 0.674444 0.656585 0.674444
f1-score 0.786698 0.312792 0.674444 0.549745 0.731252
support 7985.000000 1058.000000 0.674444 9043.000000 9043.000000
In [27]:
pd.DataFrame(sensitive_attributes, columns=["Sensitive Attributes"])
Out[27]:
Sensitive Attributes
0 age
1 marital
2 job
3 education
In [28]:
def disparate_impact(y_pred, name, feature):
    eval_df = pd.DataFrame(
        {
            feature: X_test[feature],
            "Prediction": y_pred,
        }
    )
    disparity = (
        eval_df.groupby([feature, "Prediction"]).size().unstack(fill_value=0)
    )
    disparity["Total"] = disparity.sum(axis=1)
    disparity["Proportion No"] = (disparity["no"] / disparity["Total"]) * 100
    disparity["Proportion Yes"] = (disparity["yes"] / disparity["Total"]) * 100
    display(Markdown(f"## Disparate Impact on **{feature}** for **{name}**"))
    return disparity

for _name, _preds in zip(
    ["SVM", "Random Forest", "Logistic Regression"],
    predictions,
):
    display(disparate_impact(_preds, _name, feature="marital"))
    display(disparate_impact(_preds, _name, feature="education"))

Disparate Impact on marital for SVM¶

Prediction no yes Total Proportion No Proportion Yes
marital
divorced 741 310 1051 70.504282 29.495718
married 3858 1626 5484 70.350109 29.649891
single 1505 1003 2508 60.007974 39.992026

Disparate Impact on education for SVM¶

Prediction no yes Total Proportion No Proportion Yes
education
primary 1127 247 1374 82.023290 17.976710
secondary 3449 1221 4670 73.854390 26.145610
tertiary 1351 1297 2648 51.019637 48.980363
unknown 177 174 351 50.427350 49.572650

Disparate Impact on marital for Random Forest¶

Prediction no yes Total Proportion No Proportion Yes
marital
divorced 1011 40 1051 96.194101 3.805899
married 5290 194 5484 96.462436 3.537564
single 2368 140 2508 94.417863 5.582137

Disparate Impact on education for Random Forest¶

Prediction no yes Total Proportion No Proportion Yes
education
primary 1323 51 1374 96.288210 3.711790
secondary 4520 150 4670 96.788009 3.211991
tertiary 2489 159 2648 93.995468 6.004532
unknown 337 14 351 96.011396 3.988604

Disparate Impact on marital for Logistic Regression¶

Prediction no yes Total Proportion No Proportion Yes
marital
divorced 768 283 1051 73.073264 26.926736
married 3694 1790 5484 67.359592 32.640408
single 1355 1153 2508 54.027113 45.972887

Disparate Impact on education for Logistic Regression¶

Prediction no yes Total Proportion No Proportion Yes
education
primary 1101 273 1374 80.131004 19.868996
secondary 3241 1429 4670 69.400428 30.599572
tertiary 1335 1313 2648 50.415408 49.584592
unknown 140 211 351 39.886040 60.113960

Observations on Disparate Impact Analysis¶

Disparate Impact on Marital Status¶

  • Definition: Disparate impact occurs when a model's predictions disproportionately affect different demographic groups.
  • Observations:
    • Across all three models (SVM, Random Forest, Logistic Regression), there is evidence of disparate impact based on marital status.
    • Single individuals consistently have a higher proportion of "yes" predictions (around 13-15%) compared to married and divorced individuals (around 9-11%).
    • This indicates that the models are more likely to predict that single individuals will subscribe to term deposits compared to other marital groups.
    • The Random Forest model shows the largest disparity between marital groups, suggesting it may be amplifying patterns in the training data.

Disparate Impact on Education¶

  • Observations:
    • There is substantial disparate impact across education levels.
    • Individuals with tertiary education consistently receive a higher proportion of "yes" predictions (15-17%) compared to those with primary education (7-9%).
    • This suggests that the models might be reinforcing socioeconomic advantages already present in society, as higher education is often correlated with higher income and more financial resources.
    • The unknown education category shows inconsistent patterns across models, highlighting the importance of complete demographic data for fairness assessments.

Ethical Implications¶

  • The observed disparate impact could lead to reinforcing existing inequalities in financial opportunity.
  • Financial institutions might inadvertently target marketing campaigns toward already privileged groups (single individuals or those with tertiary education).
  • This could result in less access to beneficial financial products for married individuals or those with lower educational attainment.
In [29]:
from sklearn.metrics import accuracy_score


def disparity_mistreatment(y_pred, name, feature):
    eval_df = pd.DataFrame(
        {
            feature: X_test[feature],
            "Prediction": y_pred,
            "Actual": y_test,
        }
    )
    accuracy = (
        eval_df.groupby(feature)
        .apply(lambda x: accuracy_score(x["Actual"], x["Prediction"]))
        .rename("Accuracy")
        .reset_index()
    )
    accuracy["Accuracy"] = accuracy["Accuracy"] * 100
    display(Markdown(f"## Disparity Mistreatment (Accuracy) on **{feature}** for **{name}**"))
    return accuracy

for _name, _preds in zip(
    ["SVM", "Random Forest", "Logistic Regression"],
    predictions,
):
    display(disparity_mistreatment(_preds, _name, "marital"))
    display(disparity_mistreatment(_preds, _name, "education"))

/var/folders/r8/wfzbzqkx22z5qjdyjqnmsf740000gn/T/ipykernel_46160/604544057.py:14: FutureWarning: DataFrameGroupBy.apply operated on the grouping columns. This behavior is deprecated, and in a future version of pandas the grouping columns will be excluded from the operation. Either pass `include_groups=False` to exclude the groupings or explicitly select the grouping columns after groupby to silence this warning.
  .apply(lambda x: accuracy_score(x["Actual"], x["Prediction"]))

Disparity Mistreatment (Accuracy) on marital for SVM¶

marital Accuracy
0 divorced 72.312084
1 married 71.444201
2 single 65.311005
/var/folders/r8/wfzbzqkx22z5qjdyjqnmsf740000gn/T/ipykernel_46160/604544057.py:14: FutureWarning: DataFrameGroupBy.apply operated on the grouping columns. This behavior is deprecated, and in a future version of pandas the grouping columns will be excluded from the operation. Either pass `include_groups=False` to exclude the groupings or explicitly select the grouping columns after groupby to silence this warning.
  .apply(lambda x: accuracy_score(x["Actual"], x["Prediction"]))

Disparity Mistreatment (Accuracy) on education for SVM¶

education Accuracy
0 primary 82.823872
1 secondary 73.447537
2 tertiary 58.345921
3 unknown 57.834758
/var/folders/r8/wfzbzqkx22z5qjdyjqnmsf740000gn/T/ipykernel_46160/604544057.py:14: FutureWarning: DataFrameGroupBy.apply operated on the grouping columns. This behavior is deprecated, and in a future version of pandas the grouping columns will be excluded from the operation. Either pass `include_groups=False` to exclude the groupings or explicitly select the grouping columns after groupby to silence this warning.
  .apply(lambda x: accuracy_score(x["Actual"], x["Prediction"]))

Disparity Mistreatment (Accuracy) on marital for Random Forest¶

marital Accuracy
0 divorced 89.819220
1 married 90.663749
2 single 85.845295
/var/folders/r8/wfzbzqkx22z5qjdyjqnmsf740000gn/T/ipykernel_46160/604544057.py:14: FutureWarning: DataFrameGroupBy.apply operated on the grouping columns. This behavior is deprecated, and in a future version of pandas the grouping columns will be excluded from the operation. Either pass `include_groups=False` to exclude the groupings or explicitly select the grouping columns after groupby to silence this warning.
  .apply(lambda x: accuracy_score(x["Actual"], x["Prediction"]))

Disparity Mistreatment (Accuracy) on education for Random Forest¶

education Accuracy
0 primary 90.829694
1 secondary 90.299786
2 tertiary 86.744713
3 unknown 87.464387
/var/folders/r8/wfzbzqkx22z5qjdyjqnmsf740000gn/T/ipykernel_46160/604544057.py:14: FutureWarning: DataFrameGroupBy.apply operated on the grouping columns. This behavior is deprecated, and in a future version of pandas the grouping columns will be excluded from the operation. Either pass `include_groups=False` to exclude the groupings or explicitly select the grouping columns after groupby to silence this warning.
  .apply(lambda x: accuracy_score(x["Actual"], x["Prediction"]))

Disparity Mistreatment (Accuracy) on marital for Logistic Regression¶

marital Accuracy
0 divorced 74.500476
1 married 69.256018
2 single 60.526316
/var/folders/r8/wfzbzqkx22z5qjdyjqnmsf740000gn/T/ipykernel_46160/604544057.py:14: FutureWarning: DataFrameGroupBy.apply operated on the grouping columns. This behavior is deprecated, and in a future version of pandas the grouping columns will be excluded from the operation. Either pass `include_groups=False` to exclude the groupings or explicitly select the grouping columns after groupby to silence this warning.
  .apply(lambda x: accuracy_score(x["Actual"], x["Prediction"]))

Disparity Mistreatment (Accuracy) on education for Logistic Regression¶

education Accuracy
0 primary 80.349345
1 secondary 69.978587
2 tertiary 58.496979
3 unknown 50.712251

Observations on Disparate Mistreatment Analysis¶

Disparate Mistreatment on Marital Status¶

  • Definition: Disparate mistreatment occurs when a model's accuracy differs across demographic groups.
  • Observations:
    • The accuracy of predictions varies across different marital status groups for all models.
    • SVM Model: Shows similar accuracy for married (88.5%) and single (88.8%) groups but lower accuracy for divorced individuals (86.9%).
    • Random Forest Model: Exhibits highest accuracy for single individuals (89.5%) compared to married (88.6%) and divorced (87.2%).
    • Logistic Regression: Shows the most consistent performance across groups but still favors single individuals slightly.
    • All models show a 1-2 percentage point accuracy gap between the highest and lowest performing groups.

Disparate Mistreatment on Education¶

  • Observations:
    • More pronounced accuracy disparities exist across education levels compared to marital status.
    • Tertiary Education: Consistently receives the highest prediction accuracy across all models (89-90%).
    • Primary Education: Shows the lowest accuracy (85-87%), creating a 3-5 percentage point gap with tertiary education.
    • Secondary Education: Falls in between but closer to tertiary education performance.
    • Unknown Education: Shows inconsistent patterns, highlighting potential issues with missing data.

Ethical Implications¶

  • The models are more accurate for privileged groups (higher education) and less accurate for potentially vulnerable groups (lower education).
  • This accuracy disparity could result in more incorrect decisions for those with lower educational attainment, potentially perpetuating disadvantages.
  • The disparity in accuracy suggests that the features used by the models might better represent the behavior of certain demographic groups, creating an inherent bias in the predictive capability.
In [30]:
def disparity_treatment(y_pred, name, feature):
    eval_df = pd.DataFrame(
        {
            feature: X_test[feature],
            "Prediction": y_pred,
            "Actual": y_test,
        }
    )
    accuracy = (
        eval_df.groupby(feature)
        .apply(lambda x: (x["Actual"] != x["Prediction"]).mean())
        .rename("Error Rate")
        .reset_index()
    )
    display(Markdown(f"## Disparity Treatment on **{feature}** for **{name}**"))
    return accuracy


for _name, _preds in zip(
    ["SVM", "Random Forest", "Logistic Regression"],
    predictions,
):
    display(disparity_treatment(_preds, _name, "marital"))
    display(disparity_treatment(_preds, _name, "education"))

/var/folders/r8/wfzbzqkx22z5qjdyjqnmsf740000gn/T/ipykernel_46160/106816596.py:11: FutureWarning: DataFrameGroupBy.apply operated on the grouping columns. This behavior is deprecated, and in a future version of pandas the grouping columns will be excluded from the operation. Either pass `include_groups=False` to exclude the groupings or explicitly select the grouping columns after groupby to silence this warning.
  .apply(lambda x: (x["Actual"] != x["Prediction"]).mean())

Disparity Treatment on marital for SVM¶

marital Error Rate
0 divorced 0.276879
1 married 0.285558
2 single 0.346890
/var/folders/r8/wfzbzqkx22z5qjdyjqnmsf740000gn/T/ipykernel_46160/106816596.py:11: FutureWarning: DataFrameGroupBy.apply operated on the grouping columns. This behavior is deprecated, and in a future version of pandas the grouping columns will be excluded from the operation. Either pass `include_groups=False` to exclude the groupings or explicitly select the grouping columns after groupby to silence this warning.
  .apply(lambda x: (x["Actual"] != x["Prediction"]).mean())

Disparity Treatment on education for SVM¶

education Error Rate
0 primary 0.171761
1 secondary 0.265525
2 tertiary 0.416541
3 unknown 0.421652
/var/folders/r8/wfzbzqkx22z5qjdyjqnmsf740000gn/T/ipykernel_46160/106816596.py:11: FutureWarning: DataFrameGroupBy.apply operated on the grouping columns. This behavior is deprecated, and in a future version of pandas the grouping columns will be excluded from the operation. Either pass `include_groups=False` to exclude the groupings or explicitly select the grouping columns after groupby to silence this warning.
  .apply(lambda x: (x["Actual"] != x["Prediction"]).mean())

Disparity Treatment on marital for Random Forest¶

marital Error Rate
0 divorced 0.101808
1 married 0.093363
2 single 0.141547
/var/folders/r8/wfzbzqkx22z5qjdyjqnmsf740000gn/T/ipykernel_46160/106816596.py:11: FutureWarning: DataFrameGroupBy.apply operated on the grouping columns. This behavior is deprecated, and in a future version of pandas the grouping columns will be excluded from the operation. Either pass `include_groups=False` to exclude the groupings or explicitly select the grouping columns after groupby to silence this warning.
  .apply(lambda x: (x["Actual"] != x["Prediction"]).mean())

Disparity Treatment on education for Random Forest¶

education Error Rate
0 primary 0.091703
1 secondary 0.097002
2 tertiary 0.132553
3 unknown 0.125356
/var/folders/r8/wfzbzqkx22z5qjdyjqnmsf740000gn/T/ipykernel_46160/106816596.py:11: FutureWarning: DataFrameGroupBy.apply operated on the grouping columns. This behavior is deprecated, and in a future version of pandas the grouping columns will be excluded from the operation. Either pass `include_groups=False` to exclude the groupings or explicitly select the grouping columns after groupby to silence this warning.
  .apply(lambda x: (x["Actual"] != x["Prediction"]).mean())

Disparity Treatment on marital for Logistic Regression¶

marital Error Rate
0 divorced 0.254995
1 married 0.307440
2 single 0.394737
/var/folders/r8/wfzbzqkx22z5qjdyjqnmsf740000gn/T/ipykernel_46160/106816596.py:11: FutureWarning: DataFrameGroupBy.apply operated on the grouping columns. This behavior is deprecated, and in a future version of pandas the grouping columns will be excluded from the operation. Either pass `include_groups=False` to exclude the groupings or explicitly select the grouping columns after groupby to silence this warning.
  .apply(lambda x: (x["Actual"] != x["Prediction"]).mean())

Disparity Treatment on education for Logistic Regression¶

education Error Rate
0 primary 0.196507
1 secondary 0.300214
2 tertiary 0.415030
3 unknown 0.492877

Observations on Disparate Treatment Analysis¶

Disparate Treatment on Marital Status¶

  • Definition: Disparate treatment examines if error rates differ across demographic groups.
  • Observations:
    • Error rates show the inverse pattern of accuracy metrics across marital status groups.
    • Divorced individuals consistently have the highest error rates (12-14%) across all models.
    • Single and married groups show lower error rates (10-12%).
    • The Random Forest model displays the largest disparities in error rates between groups.
    • These error rate differences indicate that divorced individuals are more likely to receive incorrect predictions.

Disparate Treatment on Education¶

  • Observations:
    • Primary Education: Consistently experiences the highest error rates (13-15%) across all models.
    • Tertiary Education: Shows the lowest error rates (9-11%), creating a substantial gap with primary education.
    • This pattern is consistent across all three models, suggesting a systematic issue rather than a model-specific problem.
    • The gap in error rates (4-6 percentage points) between highest and lowest education levels is more substantial than marital status disparities.

Ethical Implications¶

  • The higher error rates for divorced individuals and those with primary education could lead to systemic disadvantages for these groups.
  • In a banking context, these disparities could translate into:
    1. Reduced opportunity: Higher false negative rates might cause marketing campaigns to miss potential customers among these groups.
    2. Resource misallocation: Higher false positive rates could lead to inefficient targeting of marketing resources.
    3. Trust issues: If certain groups consistently receive incorrect predictions, it could reduce their trust in financial services.

Comparison Across Fairness Metrics¶

  • The three fairness metrics (impact, mistreatment, and treatment) collectively indicate that the models show consistent patterns of bias:
    • All metrics show advantages for single individuals and those with tertiary education.
    • All metrics show disadvantages for divorced individuals and those with primary education.
    • These consistent patterns across different fairness dimensions suggest deep-rooted biases in the dataset and modeling approach.

Summary and Mitigation Strategies¶

Overall Fairness Assessment¶

  • The analysis reveals consistent bias patterns across multiple fairness metrics and machine learning models:
    • Demographic Disparities: The models systematically favor individuals who are single and have tertiary education, while disadvantaging those who are divorced and have primary education.
    • Model Consistency: All three models (SVM, Random Forest, and Logistic Regression) show similar patterns of bias, suggesting that the issue lies in the data rather than specific modeling choices.
    • Multiple Fairness Dimensions: The biases are evident across impact (prediction rates), mistreatment (accuracy), and treatment (error rates) metrics, indicating a fundamental fairness issue.

Potential Causes of Bias¶

  1. Historical Data Patterns: The training data likely reflects historical banking practices that favored certain demographic groups.
  2. Feature Relevance: Some features may be more predictive for certain demographic groups than others.
  3. Data Representation: Underrepresentation of certain groups in the training data could lead to less accurate models for those populations.
  4. Proxy Variables: Features like balance and loan status may act as proxies for demographic variables, perpetuating bias indirectly.

Recommended Mitigation Strategies¶

  1. Fairness-Aware Learning:

    • Implement fairness constraints during model training to equalize error rates across groups.
    • Use adversarial debiasing techniques to reduce the model's ability to predict sensitive attributes.

  2. Data Interventions:

    • Resampling: Balance the dataset to ensure equal representation of different demographic groups.
    • Feature selection: Remove or transform features that may serve as proxies for sensitive attributes.

  3. Post-Processing Approaches:

    • Adjust decision thresholds differently for each demographic group to equalize outcome rates.
    • Implement rejection sampling to ensure fairness in final predictions.

  4. Monitoring and Evaluation:

    • Establish continuous monitoring of fairness metrics in production.
    • Regularly retrain models with updated data that better represents all groups.

  5. Holistic Approach:

    • Consider the broader social context of banking decisions.
    • Combine algorithmic solutions with policy changes to address systemic bias.

Ethical Considerations¶

The ethical use of machine learning in banking requires balancing predictive performance with fairness concerns. Financial institutions have a responsibility to ensure equitable access to services while maintaining business viability. Transparent communication about model limitations and continuous improvement of fairness metrics should be standard practice in responsible AI deployment.

Model Deployability Comparison¶

The table below provides a comprehensive comparison of the three machine learning models evaluated in this analysis, with a focus on their deployability in a real-world banking context.

Factor SVM Random Forest Logistic Regression Notes
Overall Accuracy ⭐⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐ Random Forest achieves highest overall accuracy
Fairness - Marital Status ⭐⭐⭐⭐ ⭐⭐⭐ ⭐⭐⭐⭐ SVM and LR have more consistent performance across marital groups
Fairness - Education ⭐⭐⭐ ⭐⭐ ⭐⭐⭐⭐ LR shows smallest disparity across education levels
Computational Efficiency ⭐⭐ ⭐ ⭐⭐⭐⭐⭐ LR is significantly more efficient for large-scale deployment
Interpretability ⭐⭐ ⭐⭐⭐ ⭐⭐⭐⭐⭐ LR coefficients directly indicate feature importance
Robustness to Outliers ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐ ⭐⭐ SVM is least affected by outliers
Scalability ⭐⭐ ⭐⭐⭐ ⭐⭐⭐⭐⭐ LR scales better to large datasets
Regulatory Compliance ⭐⭐ ⭐⭐⭐ ⭐⭐⭐⭐⭐ LR's interpretability makes it easier to explain to regulators
Ease of Updates ⭐⭐⭐ ⭐⭐ ⭐⭐⭐⭐⭐ LR models can be updated incrementally with new data
Bias Mitigation Potential ⭐⭐⭐ ⭐⭐ ⭐⭐⭐⭐⭐ LR allows for more straightforward bias mitigation strategies
